How to create/use Q-Cal Templates for Q-Play Template solution

How to create/use Q-Cal Templates for Q-Play Template solution

How to create a Q-Cal Screen Design.

If you want to add a dynamic element to your Q-Play template, we can create a relevant template in Q-Cal. Then we also showcase how the two systems work together.

  1. Sign in to Q-Cal.

  2. Click on Design

    Interface header with 'Q-Cal' logo, main menu, views selection, highlighted 'Design' button, and search bar.



  3. Choose a display type

  4. Pick a design.

  5. Configure the design

  6. Name it.

  7. Save.

You can the now find the design under Main Menu > Screen Designs. Here you can customize the design, such as making changes to the HTML and the CSS, or change the colors.


How to show the Q-Cal SignageView in Q-Play.

  1. Click on Views, and then select SignageViews.
    Q-Cal interface showcasing 'Views' dropdown menu with options for Meeting Room Displays and SignageViews, alongside navigation for different calendar views.



  2. Click the "+".
    SignageViews management screen with options to search, sort, and add new views, as well as columns for preview, code, design, binding, and activity logs.



  3. Here you'll need to select the design you made, name the SignageView and give it a description. When done press Save & Close.

  4. The SignageView is now created, and is visible under SignageViews.

  5. Copy the Q-Play code and enter it in the booking app in Q-Play
SignageViews list with preview options, Q-Play codes for each view, design details, bindings, creation and update dates, and activity monitoring features.
